X-fix timber connector C 63-100-90

Primarily developed for the corner connection of standing walls and for use in modular construction with wall thicknesses from 60 to over 100 mm.

Technical data:

Length: 100 mm

Width: 63 mm

Height: 90 mm

Material: Birch plywood

Milling pattern: PDF

Advantages
• Very fast assembly time
• Form-fitting connection, ideal for visible surfaces
• No beam tension required for ceiling connections
• Self-tightens large-format ceiling panels due to the wedge shape
